Description
Frequency Band
UHF 860-960 MHz
Chip Type
Impinj ® M730
International Standard
ISO/IEC 18000-6C
EPC Memory
128 bits
TID Memory
48 bits
Certificate
WEEE compliant
Specifications
Physical Specifications
Material: Clear PET
Label Size: 96×26 mm
Antenna Size: 94×24 mm
Technical Parameters
Operating Frequency: 860~960 Mhz
Communication Protocol:
ISO/IEC 18000 -6c
Operating mode: Passive
ESD Voltage Immunity: Max.2000V(HBM)
Packaging
Packing Format:
In roll, vacuumed packing in ESD bag
Core ID: 3 inch(76.20 ± 0.50 mm)
Packing Quantity: 7500 Pcs/roll, 4 rolls/carton
Additional Information
Operating Environment:
-5°C~60°C, 20%~80% RH
Storage Environment:
20°C~30°C, 20%~60% RH
Passed Test:
REACH Regulation(EC) No.1907/2006
RoHS EU Directive 2011/65/EC and Directive(EU) 2015/863
Handling Precautions:
Ensure the label is waterproof and avoidviolent impacts, squeezing, or bending.
Application:
Inventory and Logistics, Sports Timing, Supply Chain Management.
Chip Characteristics
Chip Manufacturer: Impinj®
Chip Type: Impinj® M730
EPC memory: 128 Bits(Read & Write)
Password: 32 Bits Access | 32 Bits Kill
TID memory: 48 Bits(Read only)
Read sensitivity: -24 dBm
Write sensitivity: -21 dBm
AutoTune™ Automatic RF Tuning: V2
Enduro™ Bonding Method: V1
Integra™ Data Diagnostics: Yes
Fast Encoding Speeds: Yes
FastID™ High-speed Read Capability: Yes
TagFocus™ Read Redundancy Prevention: Yes
Write Endurance: 100,000 times
Data Retention Time: 50 years
