Description
Frequency Band
UHF 860-960 MHz
Chip Type
Impinj Monza R6-P
International Standard
EPC C1G2 (ISO18000-6C) and EPC Gen2v2
EPC Memory
128 | 96 bits
User Memory
32 | 64 bits
Certificate
WEEE compliant
Specifications
Physical Specifications
Material: PET & Aluminum Foil & Foam
Label Size: 80×40×1 mm
IP Rating: IP68; test for 5 hours at 1 meter deep water
Personalized Printing: Logo, barcode, QR code, number printing, encoding, etc.
Additional Info
Support Printer:
SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc
Application:
Metallic container tracking, equipment and device tracking, Warehouse shelf, Automotive components tracking, IT asset tracking, etc
RF Specifications
IC type: Impinj Monza® R6P
Support protocols: ISO 18000-6C, EPC Global Gen2v2
Frequency: 860–960 MHz
Read/Write EPC: 128 | 96 bits
Read Only TID: 48 bits
Read/Write User Memory: 32 | 64 bits
Read Sensitivity: -22 dBm
Write Sensitivity: -17 dBm
Read Distance (2W ERP FCC): 7m on-metal, 4m off-metal
Read Distance (2W ERP ETSI): 7m on-metal, 3m off-metal
Tag data protection features: Access / Kill short-range mode
Data Retention: > 10 years
Write Endurance: 100,000 times
Environmental Spec
Operating Limits: -40° ~ 85°C
Storage Limits: 23 ± 3°C
Packaging
Packing quantity: 500 pcs/roll
Packing method: Packed in roll
Reel core inner diameter: 76.2 mm /3″
Installation: Directly stick on objects
