MORX 64x18mm

The Flexible & Printable UHF On-Metal Label is a durable, customizable, high-performance RFID label that can be easily printed and encoded. The label is ideal for metallic container tracking, equipment & device tracking, warehouse shelf tracking, automotive components tracking, IT asset tracking, etc. It can be stuck to metallic assets easily, especially on irregular and uneven surfaces.

Description

Frequency Band

UHF 860-960 MHz

Chip Type

NXP UCODE 8

International Standard

EPC C1G2 (ISO18000-6C) and EPC Gen2v2

EPC Memory

128 bits

IP Rating

IP68, test for 5 hours at 1m deep water

Certificate

WEEE compliant

Physical Specifications

Material: PET & Aluminum Foil & Foam
Label Size: 64×6×1 mm
IP Rating: IP68; test for 5 hours at 1 meter deep water
Personalized Printing: Logo, barcode, QR code, number printing, encoding, etc.

Additional Info

Support Printer:
SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc
Application:
Metallic container tracking, equipment and device tracking, Warehouse shelf, Hand tools, Weapon, IT asset tracking, Cosmetic, Wine etc

RF Specifications

IC type: NXP ® Ucode®8
Support protocols: ISO|IEC 18000-6C EPC Global Gen2
Frequency: 860–960 MHz
Read/Write EPC: 128 bits
Read/Write User Memory: 32 bits
Read Sensitivity: -23 dBm
Write Sensitivity:-18 dBm
Read Distance (2W ERP FCC): 4m on-metal, 4.5m on-liquid
Read Distance (2W ERP ETSI): 3.5m on-metal, 6.5m on-liquid
Access password 32b: 32 bits
Data Retention: > 10 years
Write Endurance: 100,000 times

Environmental Spec

Operating Limits: -40° ~ 85°C
Storage Limits: -40° ~ 120°C

Packaging

Packing quantity: 500 pcs/roll
Packing method: Packed in roll
Reel core inner diameter: 76.2 mm /3″
Installation: Directly stick on objects
